Encapsulated Resistor
Ohmite offers the design and materials expertise to meet your specific resistor package requirements.
Key features and benefits of Ohmite encapsulated resistors:
· Ohmite non-inductive ceramic resistor high energy, voltage and power
performance.
· Rugged design to meet mechanical shock and vibration requirements.
· Machined aluminum case and packaging materials suitable for harsh
industrial and aerospace applications.
· Sealed package for protection from contaminants.
· Multiple series-parallel connected or multiple individual
resistors within a single package.
· Package shapes and sizes to fit available space.
MATERIAL CHARACTERISTICS
| Characteristic | |
| Electrical resistance (R) | +/- 5%, 10%, or 20% |
| Rated peak pulse energy (Type SP / Type AS and BA)* | 630 joules / 5,200 joules |
| Operating Temperature | - 55°C to + 230°C |
| Typical weight | 500 g |
